NXP i.MX7D Microcontroller
1.0 GHz 2 x ARM® Cortex™ A7
266 Mhz 1 x ARM® Cortex™ M4
1 GB DDR3
4 KB EEPROM
16 MB QSPI NOR
4 GB eMMC
3.3v microSD
LCD Type: TFT
Screen Size: 5" Diagonal
Display Format: 480x854 Dots
Color: 16.7M
Mode: IPS Transmissive/Normally Black
Viewing Direction: 80°/80°/80°/80°
Brightness: 470 nits
Backlight Type: White LED
Backlight Adjust: Automatic with ambient light sensor
Operating Temperature -20°C +70°C
Factory installed screen protector
Projective Capacitive Touch With 5 Simultaneous Touch Points
1 x User Button
1 x Power Button
300mW internal speaker internal microphone
1.7G Linear Resonant Actuator
2 x Charging Status Leds
2 x User Leds
3D accelerometer and 3D gyroscope
5 MP Auto focus color rear camera with flash
Internal 7.4V 8000mAh Li-Po battery
Basic Rate (BR), Enhanced Data Rate (EDR) and Low
Energy (LE). multi connection capable up to 7 devices for
BR/EDR plus up to 10 devices for LE.
4G with 3G/2G fallback
LTE Uplink up to 50 Mbps, Downlink up to 150 Mbps
HSPA+ Uplink up to 5.76 Mbps, Downlink up to 42.0 Mbps
UMTS Uplink/Downlink up to 384 kbps
Digital audio interface over Bluetooth
1.8V/3V microSIM Card
GPS + GLONASS
USB 2.0 HS OTG with micro B connector
Printing method: Thermal dot line printing
Total dots per line: 576 dots
Resolution: W8 dots/mm x H16 dots/mm
Paper feed pitch: 0.03125mm
Print Width: 72 mm
Paper Width: 80±1mm
Paper roll diameter: 50mm(max)
L: 236mm x W: 85mm(105mm) x D: 39mm(55mm)
720 grams (except the paper roll)
Soft touch coated ABS
ANDROID 7.1.2(Nougat)
BareMetal
|
